JOHNSON CONTROLS
148
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 6 – USER INTERFACE CONTROL CENTER
BACNET
NAME
USER INTERFACE
NAME
READ/
WRITE
BACNET
OBJECT
TYPE AND
INSTANCE
MODBUS
REGISTER
ADDRESS
POINTS LIST DESCRIPTION
FURN_OUT_5
Elect Heat Stage 5
Status Staged Gas
Furn 3 Low Status
Mod Gas Furn 3
Low Status
R BI30 1311
Displays The Status Of The Control Output
To The Indicated Heat Section: 0=Off
1=On
FURN_OUT_6
Elect Heat Stage 6
Status Staged Gas
Furn 3 High Status
Mod Gas Furn 3
High Status
R BI31 1312
Displays The Status Of The Control Output
To The Indicated Heat Section: 0=Off
1=On
FURN_OUT_7
Elect Heat Stage
7 Status Mod Gas
Furn 1B Status
R BI32 1313
Displays The Status Of The Control Output
To The Indicated Heat Section: 0=Off
1=On
HEAT_ENABLE Heating System R/W AV83 BV07 1108
A BAS Command That Allows The Heating
Function To Be Turned On/Off: 0=Enabled
1=Disabled
HEAT_ENT_
TEMP
Heat Entering Temp R AI22 535
Displays The Actual Temp Of The Air
Entering The Elect, Staged Gas, Or Mod
Gas Heat Sections
HEAT_STAGES
Electric Heat Stages
Or Gas Heat Stages
R AI23 536
Displays The Number Of Elect Or Staged
Gas Heat Stages Available
HEAT_
VACTION
Hw Valve Action R/W AV84 BV08 1109
A BAS Command That Allows The Hot
Water/Steam Valve Action To Be Changed:
0=Direct 1=Reverse
HEATING_SAT
Heating Suppy Sir
Temp Sp (VAV Or
FlexSys)
R/W AV09 1034
Displays The Active Supply Air Temp Sp
For Heating
HEATING_VLV Heating Valve R AI24 537
Displays The Ouput From The Control To
A Hw/Steam Valve Or Mod Gas Heat Valve
(%)
HW_FRZ_STAT
Hw/Steam Coil
Freezestat Status
R BI33 1314
Displays The Status Of The Freezestat On
Units With Hw/Steam Heat: 0=No Fault
1-Faulted
LOCAL_STOP Local Stop Status R BI34 1315
Displays The Status Of The 24Vac Input
To The Control Board Through The SD
Terminal And/Or The Unit On/Off Switch
MAX_BYPASS
Maximum Bypass
Sp (FlexSys)
R/W AV10 1035
Displays The Max Setting For The Bypass
Damper
MAX_FLOW_
DV
Outside Air Max
Flow Sp
R/W AV11 1036
Displays The Max Airow For Demand
Ventilationwith An Airow Station (CFM)
MECH_LCK_
TMP
Mech Cooling
Lockout Sp
R/W AV12 1037
Displays The Min OA Temp At Which Mech
Cooling Is Allowed To Operate
MIN_FLOW_DV
Outside Air Min
Flow Sp
R/W AV13 1038
Displays The Min Airow For Demand
Ventilation With An Airow Station (CFM)
TABLE 53 – BACNET MS/TP, MODBUS, BACNET IP (SEE NOTES AT END OF TABLE) (CONT'D)
