Johnson Controls 100 Series User Manual

JOHNSON CONTROLS
151
SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
BACNET
NAME
USER INTERFACE
NAME
READ/
WRITE
BACNET
OBJECT
TYPE AND
INSTANCE
MODBUS
REGISTER
ADDRESS
POINTS LIST DESCRIPTION
RA_DIFF_BAS
Return Air Diff Sp
BAS (FlexSys)
R/W AV42 1067
Displays The Active Temp Sp That Causes
The Unit To Switch From Cooling W/O
Bypass To Cooling W/Bypass
RAT_COOL_SP
Cooling Return Air
Temp Sp (VAV Or
FlexSys)
R/W AV23 1048
Displays The Active Return Air Temp Sp
For Cooling
RAT_HIGH_
SAT
Ra Temp Sp For
Hi Supply Air Temp
(VAV, And Only If
Sat Reset Method Is
Return Air)
R/W AV24 1049
Displays The Ra Temp Sp Used For
Switching To The High Supply Air Temp Sp
RAT_LOW_SAT
Ra Temp Sp For
Lo Supply Air Temp
(VAV, And Only If
Sat Reset Method Is
Return Air)
R/W AV25 1050
Displays The Ra Temp Sp Used For
Switching To The Low Supply Air Temp Sp
RDY_RUN_C1A
Ready To Run
Comp 1A Status
R BI40 1321
Displays The Status Of Comp 1A Ready
To Run If Comp Is Off: (Yes/No)
RDY_RUN_
C1B
Ready To Run
Comp 1B Status
R BI41 1322
Displays The Status Of Comp 1B Ready
To Run If The Comp Is Off: (Yes/No)
RDY_RUN_C2A
Ready To Run
Comp 2A Status
R BI42 1323
Displays The Status Of Comp 2A Ready
To Run If The Comp Is Off: (Yes/No)
RDY_RUN_
C2B
Ready To Run
Comp 2B Status
R BI43 1324
Displays The Status Of Comp 2B Ready
To Run If The Comp Is Off: (Yes/No)
RDY_RUN_C3A
Ready To Run
Comp 3A Status
(70-150 Ton Only)
R BI44 1325
Displays The Status Of Comp 3A Ready
To Run If The Comp Is Off: (Yes/No)
RDY_RUN_
C3B
Ready To Run
Comp 3B Status
(70-150 Ton Only)
R BI45 1326
Displays The Status Of Comp 3B Ready
To Run If The Comp Is Off: (Yes/No)
RDY_STOP_
C1A
Ready To Stop
Comp 1A Status
R BI46 1327
Displays The Status Of Comp 1A Ready
To Stop If Operating: (Yes/No)
RDY_STOP_
C1B
Ready To Stop
Comp 1B Status
R BI47 1328
Displays The Status Of Comp 1B Ready
To Stop If Operating: (Yes/No)
RDY_STOP_
C2A
Ready To Stop
Comp 2A Status
R BI48 1329
Displays The Status Of Comp 2A Ready
To Stop If Operating: (Yes/No)
RDY_STOP_
C2B
Ready To Stop
Comp 2B Status
R BI49 1330
Displays The Status Of Comp 2B Ready
To Stop If Operating: (Yes/No)
RDY_STOP_
C3A
Ready To Stop
Comp 3A Status
(70-150 Ton Only)
R BI50 1331
Displays The Status Of Comp 3A Ready
To Stop If Operating: (Yes/No)
RDY_STOP_
C3B
Ready To Stop
Comp 3B Status
(70-150 Ton Only)
R BI51 1332
Displays The Status Of Comp 3B Ready
To Stop If Operating: (Yes/No)
RET_AIR_
BY_S
Return Air Bypass
Active Sp
R AI37 550
Displays The Value (%) For The Current
Sp Of The Ra Bypass Damper Onn A
FlexSys Unit
TABLE 53 – BACNET MS/TP, MODBUS, BACNET IP (SEE NOTES AT END OF TABLE) (CONT'D)
