Table 44: Power Specifications for the JNP10K-PWR-DC2 Power Supply
SpecificationsItem
•
Minimum operating voltage: –40 VDC
•
Nominal operating voltage: –48 VDC
•
Operating voltage range: –40 VDC through –72 VDC
DC input voltage
•
76-A maximum at minimum operating voltage (-40 VDC) with 80-A
dip switch setting and 5500-W output load.
•
64-A maximum at nominal operating voltage (–48 VDC) with 80-A
dip switch setting and 5500-W output load.
•
60-A maximum at minimum operating voltage (-40 VDC) with 60-A
dip switch setting and 4400-W output load.
•
50-A maximum at nominal operating voltage (-48 VDC) with 60-A
dip switch setting and 4400-W output load.
DC input current rating
2200 W for low input (60-A) single feed
4400 W for low input (60-A) dual feed
2750 W for high input (80-A) single feed
5500 W for high input (80-A) dual feed
Output power
Table 45 on page 113 shows the physical specifications for a JNP10K-PWR-DC2 power supply.
Table 45: Physical Specifications of a JNP10K-PWR-DC2 Power Supply
ValueSpecification
3.5 in. (8.89 cm)Height
3.6 in. (9.14 cm)Width
16.05 in. (40.77 cm)Depth
8.1 lb (3.67 kg)Weight
MX10016 Grounding Cable and Lug Specifications
For installations that require a separate grounding conductor to the chassis, the router must be adequately
grounded before power is connected to ensure proper operation and to meet safety and electromagnetic
