Juniper MX10016 Hardware Guide

Software on MX10016
The MX10016 router runs Junos OS, which provides Layer 3 routing services. The same Junos OS code
base that runs on the MX10016 router also runs on all Juniper Networks M Series, MX Series, and T Series
routers and SRX Series Services Gateways.
MX10016 Components and Configurations
Table 4 on page 31 lists the four hardware configurations for an MX10016 modular chassis—base (AC
version), and redundant (AC and DC versions)—and the components included in each configuration.
Table 4: MX10016 Hardware Configurations
Configuration ComponentsRouter Configuration
•
Chassis, including power bus
•
One Routing and Control Board
•
One control board cover panel
•
Two fan tray controllers
•
Two fan trays
•
Five 2700 W AC power supplies
•
Five power supply cover panels
•
Five Switch Fabric Boards (SFBs)
•
One SFB cover panel
•
Sixteen line card cover panels
Base AC configuration
MX10016-BASE
•
Chassis, including power bus
•
One Routing and Control Board
•
One control board cover panel
•
Two fan tray controllers
•
Two fan trays
•
Five 2500 W DC power supplies
•
Five power supply cover panels
•
Five Switch Fabric Boards (SFBs)
•
One SFB cover panel
•
Sixteen line card cover panels
Base DC configuration
MX10016-BASE
31
