Juniper MX10016 - Performing Initial Configuration

Figure 11: JNP10K-PWR-DC Power Supply
g050571
Figure 12: JNP10K-PWR-DC2 Power Supply
g100595
Table 3 on page 30 provides an overview of the differences among the power supplies.
Table 3: Power Supply Overview
Power BusWattageInput TypePower Supply Model
Standard or enhanced2700 WAC onlyJNP10K-PWR AC
Enhanced5000 W, single feed; 5500 W,
dual feed
AC, HVAC, or HVDCJNP10K-PWR-AC2
Standard or enhanced2500 WDC onlyJNP10K-PWR DC
Enhanced2750 W, single feed; 5500 W,
dual feed
DC onlyJNP10K-PWR-DC2
30
