NOTE: The calculations in this topic represent the maximum power requirements that you need
to budget for your MX10016 router configuration. The actual power consumption of your router
can be less than the calculated results shown here and will vary based on the hardware and software
configuration of your router, the amount of traffic passing through the line cards, and environmental
variables such as room temperature.
Before you begin these calculations:
•
Ensure that you understand different router configurations. See “MX10016 Components and
Configurations” on page 31.
•
Ensure that you know the power requirements of different router components. See “Power Requirements
for MX10016 Components” on page 97.
This topic describes these tasks:
1.
How to Calculate the Power Consumption of Your MX10016 Configuration | 98
2.
How to Calculate the Number of Power Supplies Required for Your MX10016 Configuration | 100
How to Calculate the Power Consumption of Your MX10016 Configuration
Use the following procedure to determine the maximum power you need to supply to the router. To
calculate the maximum power consumption, you first determine the combined maximum internal power
requirements of all the router components and then divide this result by the output power of the power
supply.
To calculate the maximum power consumption:
1. Determine the maximum power consumption of the base chassis components (that is, the components
other than the line cards). Use Table 32 on page 98 if your router is in either a base configuration or a
redundant configuration.
Table 32: Chassis Power Consumption for Standard Configurations
Redundant ConfigurationBase ConfigurationChassis Component
1100 W1100 WFan tray
350 W/330 W175 W/165 WRouting and Control Board (128G/64G) at
40° C
1200 W1000 WSwitch Fabric Board (SFB)
2650 W2275 WTotal
