2. Calculate the maximum internal power consumption of the entire router by adding in the power
requirements of each line card. See Table 33 on page 99 for a chart of the power needed for line cards.
Table 33: Line Card Power Consumption
MX10K-LC2101 (400-Gigabit
Ethernet mode at 104° F (40°
C))
MX10K-LC2101 (240-Gigabit
Ethernet mode at 104° F (40°
C))Number of Line Cards
1425 W1175 W1
2850 W2350 W2
4275 W3525 W3
5700 W4700 W4
7125 W5875 W5
8550 W7050 W6
9975 W8225 W7
11400 W9400 W8
12825 W10575 W9
14250 W11750 W10
15675 W12925 W11
17100 W14100 W12
18525 W15275 W13
19950 W16450 W14
21375 W17625 W15
22800 W18800 W16
For example, for an MX10016 with 16 MX10K-LC2101 line cards, the maximum power consumption
at 400-Gigabit Ethernet mode is:
16 * 1425 W= 22800 W
