The MX10016 cooling system components work together to keep all components within the acceptable
temperature range. If the maximum temperature specification is exceeded and the system cannot be
adequately cooled, the Routing and Control Board shuts down some or all of the hardware components.
For more information, see the following topics:
MX10016 Cooling System and Airflow
IN THIS SECTION
MX10016 Fan Trays | 46
MX10016 Fan Tray Controllers | 47
Airflow Direction in an MX10016 | 49
The cooling system in an MX10016 chassis consists of two fan trays and two fan tray controllers. An
MX10016 has an air filter on the front panel. The fans in each fan tray are numbered 0 through 10.
Two fan tray models and their associated fan tray controllers are available. All models are hot-insertable
and hot-removable. See Table 9 on page 45.
Table 9: Fan Tray Specifications
JNP10016-FAN2JNP10016-FANSpecification
JNP10016-FTC2JNP10016-FAN-CTLRCorresponding fan tray controller
model
Enhanced or standardEnhanced or standardChassis supported
2211Number of fans per fan tray
4422Number of fans per chassis
3,423 CFM per fan tray2,744.07 CFM per fan trayVolume flow at 100%
19.2R115.1X53-D30Introduced in Junos OS Release
22.4 in. (56.9 cm)22.4 in. (56.9 cm)Height
6.6 in. (16.8 cm)6.6 in. (16.8 cm)Width
45
