CAUTION: To meet safety and electromagnetic interference (EMI) requirements and
to ensure proper operation, an MX10016 must be adequately grounded before it is
connected to power.
For installations that require a separate grounding conductor attached to the chassis,
use the protective earthing terminal on the rear panel of the MX10016 to connect to
earth ground.
An AC- powered MX10016 gets additional grounding when you plug the power supply
in the router into a grounded AC power outlet by using an AC power cord appropriate
for your geographical location. See “MX10016 Power Cord Specifications” on page 104.
2. Install power supplies in the router, and apply power. See “How to Install a JNP10K-PWR-AC Power
Supply” on page 175.
Connecting DC Power to an MX10016
The overall process of powering on a DC-powered chassis involves the proper cabling of the individual
power supplies, adding the power supplies to the chassis, and supplying power. Although this sequence
can start incrementally with a single power supply, we recommend that you power on an MX10016 router
with at least three power supplies.
Each power supply input feed must be connected to a dedicated DC power source outlet.
Before you begin connecting power to the router, be sure you understand how to prevent electrostatic
discharge (ESD) damage. See “Prevention of Electrostatic Discharge Damage” on page 303.
To connect DC power to an MX10016 DC power supply, see “How to Install a JNP10K-PWR-DC Power
Supply” on page 190.
RELATED DOCUMENTATION
MX10016 Power System | 57
Removing and Installing MX10016 Power System Components | 172
Prevention of Electrostatic Discharge Damage | 303
General Safety Guidelines and Warnings | 273
149
