Juniper MX10016 Hardware Guide

NOTE: If your laptop or PC does not have a DB-9 male connector pin and you want to connect
your laptop or PC directly to an MX10016 router, use a combination of the RJ-45 cable and RJ-45
to DB-9 adapter supplied with the device and a USB to DB-9 male adapter. You must provide the
USB to DB-9 male adapter.
Table 48: Console Port Connector Pinouts for an MX10016
DescriptionSignalPin
Request to sendRTS output1
Data terminal ready
Time of day for Precision Time Protocol
(PTP). You can use DTR pins as a TOD
universal asynchronous
receiver/transmitter (UART) by using
breakout cables.
DTR output
TOD output for PTP applications
2
Transmit dataTxD output3
Signal groundSignal oround4
Signal groundSignal oround5
Receive dataRxD input6
Data carrier detect
Time of day for PTP. You can use DCD
pins as a TOD UART by using breakout
cables.
DCD input
TOD iutput for PTP applications
7
Clear to sendCTS input8
USB Port Specifications for an MX10016
The following Juniper Networks USB flash drives have been tested and are officially supported for the
USB port in the MX10016 router:
•
RE-USB-1G-S—1-gigabyte (GB) USB flash drive
121
