Table 18: Interpreting JNP10K-PWR-AC2 LEDs
DescriptionStateColorLED
The input voltage is present, but is not within normal
operating range.
BlinkingYellowINP1 or INP0 in CLI output
The input voltage is present and within normal
operating range.
SolidGreen
The power supply is switched off; voltage is zero.OffUnlit
The input voltage is present, but is not within normal
operating range.
BlinkingYellowINP2 or INP1 in CLI output
The input voltage is present and within normal
operating range.
SolidGreen
The power supply is switched off; voltage is zero.OffUnlit
The power supply output is within normal operating
range.
SolidGreenOK
The power supply output is out of the power limits
or is over-current position.
BlinkingYellow
Power supply has failed and must be replaced.SolidRed!
Power supply is functioning normally.OffUnlit
JNP10K-PWR-DC Power Supply LEDs
The JNP10K-PWR-DC power supply has four LEDs on its faceplate: INP1, INP1, PWR OK, and FAULT.
These LEDs display information about the status of the power supply. See Figure 31 on page 72.
71
