Figure 31: LEDs on a JNP10K-PWR-DC Power Supply in an MX10016
3—1— PWR OKINP1–Source input 1
4—2— FAULTINP2–Source input 2
Table 19 on page 72 describes the LEDs in on the JNP10K-PWR-DC power supply in an MX10016 chassis.
Table 19: LEDs on a DC Power Supply in an MX10016
DescriptionStateColorLED
Indicates that the DC power input voltage is not
within normal operating range.
BlinkingYellowINP1 or INP2
DC power is within the operating range (-40 VDC to
-72 VDC).
On SteadilyGreen
The power supply is switched off.OffUnlit
DC power output is within the normal operating
range.
On SteadilyGreenPWR OK
DC power output is out of the normal operating
range.
BlinkingYellow
72
