Table 23: JCS Port LEDs on the Routing and Control Board
DescriptionStateColorLED
No transceiver is present.OffUnlitLINK LEDs for
JCS Ports
(XGE0 and
XGE1)
A link is established. The interface is up.On steadilyGreen
The beacon feature is enabled.Blinking or flickeringGreen
An error has occurred.BlinkingYellow
Table 24 on page 80 describes the LEDs for the secondary SATA drives.
Table 24: Routing and Control Board SSD Status LEDs
DescriptionStateColorLED
A SATA drive is present.On steadilyGreenDISK1 and DISK2
The drive is active.BlinkingGreen
The drive is active.On steadilyYellow
A drive is not installed.UnlitDark
RELATED DOCUMENTATION
Removing and Installing Routing and Control Boards
MX10016 Switch Fabric Board
IN THIS SECTION
MX10016 Switch Fabric Board Description | 81
Switch Fabric Board LEDs | 83
80
