Page #118 background image
NOTE: For information about the actual amount of signal loss caused by equipment and other
factors, see your vendor documentation for that equipment.
2. Calculate the (P
M
) by subtracting (LL) from (P
B
):
P
B
– LL = P
M
13 dBm – 0.5 dBm [HOL] – 5 (0.5 dBm) – 2 (0.5 dBm) – 2 km (1.0 dBm/km) – 1 dB [CRM] = P
M
13 dBm – 0.5 dBm – 2.5 dBm – 1 dBm – 2 dBm – 1 dBm = P
M
P
M
= 6 dBm
The calculated power margin is greater than zero, indicating that the link has sufficient power for
transmission. Also, the power margin value does not exceed the maximum receiver input power. Refer
to the specifications for your receiver to find the maximum receiver input power.
MX10016 Alarm and Management Cable
Specifications and Pinouts
IN THIS SECTION
Console Port Connector Pinouts for an MX10016 Router | 120
USB Port Specifications for an MX10016 | 121
Management Port Connector Pinouts for an MX10016 | 122
Console Port Connector Pinouts for an MX10016 Router
The console port (labeled CON) on the RCB panel is an RS-232 serial interface that uses an RJ-45 connector
to connect to a console management device. The default baud rate for the console port is 9600 baud.
Table 48 on page 121 provides the pinout information for the RJ-45 console connector. An RJ-45 cable
and RJ-45 to DB-9 adapter are supplied with the MX10016.
120
