Figure 104: Removing an SFB from an MX10016
9. Support the SFB as you rotate the SFB 90 degrees, and place it on the antistatic mat with the printed
circuit board facing upward. Be careful not to strike the unit against any object as you carry it or to
hold the SFB by the connector edge. If you do not have an antistatic mat, have another person help
you slide the electrostatic bag over the SFB before placing it on a stable surface (see
Figure 105 on page 217).
CAUTION: Do not stack hardware components on top of one another after you
remove them. Place each component separately on an antistatic mat that is placed
on a stable, flat surface.
216
