MULTICAL®603

110
KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017

7.9 Infologger
Everytimetheinformationcodechanges,thebelow‐mentionedregistersarelogged.
Registertype Description
Date(20YY.MM.DD) Year,monthanddayofloggingtime.
Clock(hh.mm.ss) Time
Info Informationcodeonabovedate
E1 Heatenergy
E3 Coolingenergy

Itispossibletodatareadthelatest250changesoftheinformationcodeaswellasthedatesthechangesweremade.
Whentheinformationcodeisreadfromthedisplay,50changesincludingdatescanberead.Allofthe250changes
canalsobereadbymeansof
thePCprogramLogViewHCW.
INFOEVENT
Everychangeofaparameteroftheinfocoderesultsinaninfoeventiftheselectedcountrycodeisconfiguredwith
theparameter.Itisthereforenotcertainthatallparametersresultinaninfoevent.
Aninfoeventresultsinaccumulationof
theinfoeventcounteraswellasloggingintheinfologger.Thisdoesnotapply
aslongasthemeterisintransportstateorifthecalculatortopandbasearephysicallyseparated.
Reconfigurationofactiveparametersoftheinfocodewillinfluencefutureinfocodes,whereasalllogged
infocodes
remainastheywereatthetimeoflogging.
7.10 Configdatalogger
Everytimetheconfigurationischanged,thebelow‐mentionedregistertypesarelogged.Itispossibletodatareadthe
latest50changesoftheconfiglogaswellasthedatesthechangesweremade.Themeterpermitsonly50changes,
unlessyoubreakthelegalsealandcarryout
atotalresetofthemeter,whichalsoresetstheconfiglog.
Note:Thefiftiethchangeofconfigurationmustbecarriedoutontheinstallationsite,i.e.eitherviatheSETUPloopor
viaMETERTOOLHCW.
Registertype Description
Date(20YY.MM.DD) Year,monthanddayofchange
Hour(hh.mm.ss) Time
Configurationnumber Thenewconfigurationnumber
E1,E3andV1 Metercountsaresavedjustafterreconfiguration
Hourcounter Hourcounterissaved
toffset Thetemperatureoffsetvalueissaved.
V1pulsefigure ThepulsefigureofV1(imp/lorl/imp)issaved
V1q
p
 Nominalflowq
p
issaved

ThemeterwillalwayscarryoutaconfigloggingiftheuserhashadaccesstotheSETUPloop,nomatterwhetherthe
userhaschangedtheconfigurationornot.


