Kamstrup MULTICAL 603 - Communication Modules

MULTICAL®603

KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017
137

11.1 Communicationmodules
The module areas in MULTICAL

 603 can contain 2 communication modules that adapts the meter  to various
applications.
AllmoduletypesareincludedinthecomprehensivetypetestingofMULTICAL®603.Withintheframeworkofthetype
approval,theCE‐declarationandthemanufacturer’sguaranteenoothertypesofmodulesthantheoneslistedbelow
canbeused.
Moduleswithpulseconnectionareavailableintwoversions:
- withpulseinputs(In‐AandIn‐B)forcollectionofpulsesfrome.g.watermeters
- withpulseoutputs(Out‐CandOut‐D)fortransferofpulsesfrome.g.CTSsystems
Reconfigurationbetweenpulseinputsand
pulseoutputsisnotnecessaryinMULTICAL®603.Ifamodulewithpulse
inputsismountedinMULTICAL®603,themeterisautomaticallyconfiguredfor pulseinputs. Ifamodulewithpulse
outputsismountedinMULTICAL®603,themeterisautomaticallyconfiguredforpulseoutputs.
Itispossibleto
mount2modules,whichbothhavepulseinputs,i.e.therecanbeatotalof4pulseinputs.
Thepulseinputsfromthe moduleonslot1aredesignatedIn‐A1andIn‐B1.Theinputsfromthemoduleonslot2are
designatedIn‐A2andIn‐B2.

Module
variants 
Data+2pulseinputs(In‐A,In‐B) 10
Data+2pulseoutputs(Out‐C,Out‐D) 11
M‐Bus,configurable+2pulseinputs(In‐A,In‐B) 20
M‐Bus,configurable+2pulseoutputs(Out‐C,Out‐D) 21
M‐Bus,configurable+ThermalDisconnect 22
WirelessM‐Bus,configurable,868MHz+2pulseinputs(In‐A,In‐B)
1
 30
WirelessM‐Bus,configurable,868MHz+2pulseoutputs(Out‐C,Out‐D)
1
 31
Analogoutputmodule2x0/4…20mA  40
Analoginputmodule2x0/4…20mA 41
LONFT‐X3+2pulseinputs(In‐A,In‐B) 60
BACnetMS/TP+2pulseinputs(In‐A,In‐B) 66
ModbusRTU+2pulseinputs(In‐A,In‐B) 67
1
Internalorexternalantenna


