Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

KamstrupA/S∙Technicaldescription∙5512‐2029
_
A1_GB
_
06.2017
117

Informationcode Description Remedy

Displayduration5s
Communicationerror
oninputV1aswellas
wrongpulsefigureon
inputV2.
Separatethecalculator,andcheckthatULTRAFLOW®X4hasbeen
mountedcorrectlyinthescrewterminalsofinputV1.Checkthat
bothULTRAFLOW®X4areidentical.Then,repeattheprocedurein
paragraph8.1.1.1fromitem
③.

Displayduration5s
Wrongpulsefigureon
inputV1aswellas
communicationerror
oninputV2.
Theconfiglogisfull.Itisnolongerpossibletoexchange
ULTRAFLOW®X4oneitherinputV1orinputV2withasizethat
differsfromthelatestloggedsizeofV1.Separatethe
calculator,and
checkthatULTRAFLOW®X4hasbeenmountedcorrectlyinthescrew
terminalsofinputV2.CheckthatbothULTRAFLOW®X4areidentical.
Then,repeattheprocedureinparagraph8.1.1.1fromitem③.

Displayduration5s
Wrongpulsefigureon
bothinputV1and
inputV2.
Theconfig logisfull.Itisnolongerpossibletoexchange
ULTRAFLOW®X4oneitherinputV1orinputV2withasizethat
differsfromthelatestloggedsizeofV1.
8.1.2 TheneedforlongercablesbetweenMULTICAL®603andULTRAFLOW®
Ingeneral,cablesofupto10mbetweenMULTICAL®andULTRAFLOW®areallowed.Incaselongercablesareneeded,
Kamstrupcandelivertwosolutions,eitherCableExtenderBox(6699‐036)orPulseTransmitter(6699‐903).Withthese
solutions,the
cablelengthcanbeextendedupto30mor100m,respectively.Bothsolutionshaveanumberof
advantagesanddisadvantages,whichareoutlinedinthetablebelow.
Applicationoptions CableExtenderBox PulseTransm itter
Upto30mcablebetween
ULTRAFLOW®andMULTICAL®
Yes Yes
Upto100mcablebetween
ULTRAFLOW®andMULTICAL®
No Yes
Infocodesanddatacommunication
betweenULTRAFLOW®and
MULTICAL®
Yes No
Galvanicseparationbetween
ULTRAFLOW®andMULTICAL®
No Yes
IPclass
IP65 IP67

WhenPulseTransmitterisusedbetweenULTRAFLOW®andMULTICAL®,thecalculatorwillnotbeabletoestablish
datacommunicationwithULTRAFLOW®duetothegalvanicseparation.Toavoidfaultyinfocodes,itisthusnecessary
todeselecttheinfocodes basedondatacommunicationbetweenMULTICAL®andULTRAFLOW®(Info=
16‐1024‐
2048‐128‐4096‐8192‐16384‐32768).
TheaboveinfocodescanbedeselectedbymeansofthePCprogramMETERTOOLHCWbychanging,forexample,
fromCCC‐code4xxto1xx.


Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
