MULTICAL®603
KamstrupA/S∙Technicaldescription∙55122029
_
A1_GB
_
06.2017
17
3 Typeoverview
MULTICAL®603canbeorderedin countlesscombinationsasrequir ed bythecustomer. Firstselect therequired
hardwarefromthetypeoverview,andnextselecttherequiredsoftwareconfigurationviatheconfigurationnumber
(confignumber).Further,certaindataisconfiguredunderthecountrycode,whichincludese.g.thedefinitionofGMT,
theprimaryMBusaddressaswellastheyearlyandmonthlytargetdate.Throughtheseselectionsandconfigurations
MULTICAL®603canbeadjustedforitscurrenttask.
Themeterhasbeenconfiguredfromthefactoryandisreadyforuse.Itcan,however,bechanged/reconfiguredafter
installationReconfigurationcan
becarriedoutfromthemeter’sSETUPlooporbymeansofeitherMETERTOOLHCW
orREADy.ReadmoreaboutMETERTOOLHCWintheTechnicaldescription55122096andabouttheSETUPloopin
paragraph6.3.
Typenumber:
>603xxxxxxxxxxxx<
The first 4 digits of the ty pe number (603xxxxxxxxxxxx) are
written on the meter’s front and cannot be changed after
production. The last 8 digits of the type number (603xxxx
xxxxxxxx)arenotwrittenonthemeter,butcanbereadfromthe
display.
Config.number:
>ABCCCDDDEEFFGGLMNPPRRTVVVV<
The config number is not written on the meter, but can be
displayeddistributedonfourreadingsinTECHloop.
Config1:>ABCCCDDD<
Flow sensor positionMeasuring unitResolutionDisplay
code
Config2:
>EEFFGGLM<
TariffPulseinputsIntegrationmodeLeakage
Config3:>NPPRRT<
Cold water leakagePulse outputsData logger profile
Encryptionlevel
Config4:>VVVV<
Customerlabel
Serialnumber:
>xxxxxxxx/WW/yy<
Consistingof:
8digitserialnumber(xxxxxxxx)
2digitdevicecodeforextendedavailability(WW)
2digitsforproductionyear(yy)
Theuniqueserialnumberiswrittenonthemeter andcannot
bechangedafterfactoryprogramming.
Data:
During production MULTICAL® 603 is programmed with a
numberofmeasuringvalues.Seesection3.3formoredetails
aboutthesemeasuringvalues.
