7.2 Measurementofaheatpump'scoefficientofperformance
7.2.1 CoefficientofPerformance(CP)
Inhouseswithheatpumps,withacommonheatcircuit,itisappropriatetomeasureboththereleasedthermalenergy
andthegainedelectricalenergy,bas edonwhichthecoefficientofperformance(COPorCP)canbecalculated.CPis
theabbreviationof“CoefficientOfPerformance”.

Thecalculationisbasedonsimpleproportionalnumbersbetweenthecalculatedthermalenergy(E1)andtheelectrical
energy,whichismeasuredviapulseinputB(In‐B1):
 
  󰇟1󰇠
  󰇟 1󰇠


Theelectricalenergy(In‐B1)isalwaysregisteredinkWhorMWh,whereasthethermalenergy(E1)iseitherregistered
inkWh,MWh,GcalorGJdependingontheselectedB‐code.Nomatterwhichunityou choose,themetercalculates
CPcorrectly.TheCPvalueisdisplayedwithone
decimalandisavalueintheinterval0.0…19.9.
TheCPvaluecanbedisplayed,respectively,asacurrentvalue,amonthlyvalueorayearlyvalue(SCOP,Seasonal
CoefficientOfPerformance).Inaddition,theaveragingperiodofthecurrentCPvalueaswellasthecurrentpower
measuredat
pulseinputB1canbedisplayed.
CurrentCPisaveragedoveranumberofdaysandnightsselectedinthemeter’sconfiguration.Theaveragingperiod
canbeselectedintheinterval5…30daysandnights.Theaveragingperiodissetat7daysandnights,unless
otherwisestatedbythecustomer.

Note:IfdataofE1orIn‐B1ismissingforaloggingperiod,thecurrentCPisdisplayedas0.0untilthedatabasisis
sufficient.

CPdisplayrea dings 
ThetablebelowshowstheCPreadingsintheTECHloop.
Primaryreading

Secondary
reading
Displayno.

Displayreading 
CP
(movingaverage)
 2‐023‐00

 Current

power


ofIn‐B1
2‐023‐01

 Averaging

period


ofCP
2‐023‐02

 Yearly

date

2‐023‐03

