Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

114
KamstrupA/S∙Technicaldescription∙5512‐2029
_
A1_GB
_
06.2017

8 Flowsensorconnection
MULTICAL®603hasupto6pulseinputsforconnectionofflowsensorswhereV1andV2areusedforcalculating 
energy, whereas In‐A1, In‐B1, In‐A2 and In‐B2 can be used for connecting, for example, cold water meters and
electricitymeters.Thenumberofpulseinputsmay
varyaccordingtometerconfiguration.
PulsefigureandresolutionoftheV1andV2inputsareconfiguredviatheCCC‐codeinMULTICAL®603.Iftwoflow
sensors are used on V1 and V2, respectively, these two sensors must be identical as the pulse inputs share
configuration.Foranoverview
ofCCC‐codes,seeparagraph3.2.3.
Dependingonapplicationtype,MULTICAL®603canbeconnectedtooneortwoflowsensorsforenergycalculation
purposes,seeparagraph7.1forexamplesofapplicationtypes.Typically,oneflowsensorisusedinheatorcooling
installations,thisflowsensorisalwaysconnectedto
V1,regardlessifitispositionedininletoroutlet.
ConnectionPCBwiththepossibilityofV1andV2can receivepulsesfrombothelectronicandmechanicalflowsensors.
Thisenablesconnectionofalmostanytypeofflowsensorwithpulseoutput.Forflowsensorswith24Vactivepulse
output,seeparagraph8.4.
①
ULTRAFLOW®
 (seeparagraph8.1)

② Reed/relayswitch
 (seeparagraph8.2)

③ Transistor
 (seeparagraph8.3)



8.1 ULTRAFLOW®(Connectiontype 1‐2‐7‐8)
Kamstrup’sULTRAFLOW®flowsensorsaresu ppliedfromthecalculatorandconnectedaccordingtothetablebelow.
ThepowerconsumptionofULTRAFLO W®isverylowand,atthesametime,matchesthestatedbatterylifetimesof
MULTICAL®603,seeparagraph10.3.
Cable
ULTRAFLOW®
Screwterminals
V1
Screwterminals
V2
Red(3.6VDC) 9 9
Yellow(signal) 10 69
Blue(GND) 11 11

ForULTRAFLOW®,CCC‐codes1xx,4xxand5xxareused.
8.1.1 AutoDetectofULTRAFLOW®X4
AutoDetectenablestheexchangeofULTRAFLOW®X4onMULTICAL®603withoutchangingtheCCCcode.
MULTICAL®603canautomaticallyadaptitsCCCcodetomatchtheconnectedULTRAFLOW®X4viathefunctionAuto
Detect.AutoDetectisactivewithCCCcode8xx.
Auto Detect functions in such a way that MULTICAL® 603 during start up automatically retrieves the correct
informationaboutpulsefigureandq
p
fromtheconnectedULTRAFLOW®X4flowsensors.MULTICAL®603adaptsits

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
