Diagram1:TotaltypicalaccuracyofMULTICAL®603andULTRAFLOW®comparedtoEN1434‐1
2.4 Electricaldata
Calculatordata 
Typicalaccuracy
Calculator:E
c
(0.15+2/)% Sensorpair:E
t
(0.4+4/)%
Display LCD–7or8digits,digitheight8.2mm
Resolutions 999.9999‐9999.999–99999.99–999999.9–9999999
9999.9999‐99999.999–999999.99–9999999.9–99999999
Energyunits MWh–kWh–GJ–Gcal
Datalogger(EEPROM),
programmable
Loggingintervals:From
oneminutetooneyear
Loggercontent:Allregisterscanbeselected
Standardloggerprofile:20years,36months,460days,1400hours
Infologger(EEPROM) 250infocodescanbereadviaLogView,thelast50infocodesareshowninthemeter’s
display
Clock/calendar
(withbackupbattery)
Clock,calendar,
leapyearcompensation,targetdate
Daylight saving
time/wintertime(DST)
Programmableundercountrycode.
Thisfunctioncanbedisabledsothat”technicalnormaltime”isused
Timeaccuracy Withoutexternal adjustment: Lessthan15min./year
Withexternaladjustmentevery48hours: Lessthan7sfromlegaltime
Datacommunication KMP
protocolwithCRC16usedforopticalcommunication
aswellasformodules.
Poweroftemperature
sensors
10WRMS
Supplyvoltag e 3.6VDC±0.1VDC
-6,0
-4,0
-2,0
0,0
2,0
4,0
6,0
0,01 0,10 1,00 10,00
Tol [%]
q [m³/h]
MULTICAL
®
603 and ULTRAFLOW
®
qp 1,5 m³/h @ 30K
Ec+Et+Ef (EN) Ec+Et+Ef (Typ)
