MULTICAL®603

50
KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017

Pulseoutputsarebydefaultconfiguredwiththefollowingregisters:
Meterfunction Out‐C1/C2 Out‐D1/D2 Metertype
Heatmeter E1(CE+) V1(CV) 124
Heat/coolingmeter E1(CE+) E3(CE‐) 3,6
Coolingmeter E3(CE‐) V1(CV) 5
Volumemeter V1(CV)  V1(CV) 7

Theresolutionsofthepulseoutputsalwaysfollowtheleastsignificantdigitinthedisplay,whichisdeterminedbythe
CCCcode(seeparagraph3.2.3)e.g.atCCC=119:1pulse/kWhand1pulse/0.01m
3
.

Beawarethatthepulsesareaccumulatedintheintegrationintervalandsentateveryintegrationatafixed
frequency.Thisisshownintheexamplebelow.

Integrationinterval
[s]


Volumepulses
100ms


Volumepulses
10ms






PPcode96



PPcode94


Controlledou tput
Themetercanbeconfiguredfordatacommandcontrolofpulseoutputs.Ifcontrolledoutputisrequired,thePP‐code
istobeconfiguredat99.Aspreviouslydescribed,theoutputsareconfiguredinpairs(C1/ C2)and(D1/D2),which
meansthatconnectedexternalequipmentcanswitchthemeters’
outputs,inthepairsC1/C2andD1/D2,OFF(open
opto‐transistoroutput)andON(closedopto‐transistoroutput)respectivelyviaKMPdatacommands.
Outputstatuscan bereadviatheKMP‐registersandafterapower‐onresettheoutputswillhavethesamestatusas
beforethepowerfailureas
everychangeofstatusissavedinthemeter’sEEPROM.
3.2.11 Dataloggerprofile>RR<
MULTICAL

603hasapermanentmemory(EEPROM),inwhichtheresultsfromvariousdataloggersaresaved.The
dataloggerisprogrammable.TherequireddataloggerprofileisselectedviatheRR‐codeoftheconfigurationnumber.
Unlessotherwisestatedbythecustomer,theRR‐codeissetto10,which
isadefaultdataloggerprofile(equaltothe
dataloggerinMULTICAL®602).Ifdataloggingofotherregisters,differentintervalsandloggingdepthsarerequired,
otherdataloggingprofilescanbecomposedtomatchindividualrequirements.
Theprogrammabledataloggerincludesthefollowingsix dataloggers:
- Yearlylogger

- Monthlylogger
- Dailylogger
- Hourlylogger
- Minutelogger1
- Minutelogger2

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
