MULTICAL®603
22
KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017
RR‐ T‐VVVV
Dataloggerprofile
Standarddataloggerprofile
10
Encryptionlevel
Commonkey 2
Individualkey 3
Customerlabel
Seeparagraph3.2.13
0000
1
Backlightisonfor15safteractivationofpushbuttonandisonlypossiblewithcalculatortypeMC603‐F
3.2.1 Flowsensorposition>A<
TheA‐codeindicatesinstallationofflowsensorininletoroutlet.Asthedensityandheatcapacityofwatervary with
temperature, the calculator must correct for this based on installation type (A‐code). Incorrect programming or
installationleadstoerrorofmeasuring.
Seeparagraph4.3forfurtherdetailsoninstallationofflowsensorininletand
outletinheatandcoolinginstallations.
Flowsensorposition A‐code
Inlet 3
Outlet 4
3.2.2 Measuringunit>B<
TheB‐codeindicatesthemeasuringunitusedintheenergyregister.TheoptionsareGJ,kWh,MWhorGcal.
Measuringunit B‐code
GJ 2
kWh 3
MWh 4
Gcal
1
5
1
BeawarethatGcalisnotanSIunit.ReadmoreabouthowGcalissupportedbyM‐BusorwM‐Businparagraph11.
