6.1 USERloop

TheUSERloopisthemeter’sprimaryloop,whichincludesthelegalandmostusedreadings.Theloopisintendedfor
theuserandisconfiguredaccordingtotheuser’srequirementsviatheDDD‐code.Seeparagraph3.2.4forfurther
informationontheUSERloopandDDD‐codes.
Note:No
displayindexnumbersareusedinth eUS ERloop.
6.2 TECHloop

TheTECHloopisintendedforthetechnician,whoisinterestedinviewingmorereadingsthantheonesavailablein
theUSERloop.
TheTECHloopcontainsalldisplayreadings,withtheexceptionofloggedvaluesandthedifferentialregisters,andthis
loopisnotconfigurable.Themodulereadingsconsist
ofanumberoffixedreadingsandreadingsthatdependonthe
mountedmodule.
Themeter’sTECHloopisshownbelow.Youcanswitchforwardsandbackwardsbetweenthereadingsusingthearrow
keys,whileabriefactivationoftheprimarykeyswitchesbetweenprimaryandsecondaryreadings.
TECHloop Display
Primaryreading

Secondaryreading

Index
numberin
display
Logging
depth/refere
ncenumber
1 HeatenergyE1  2‐001‐00
 1.1 Dateofyearlylogger 2‐001‐01 Log01‐02
 1.2 Dataofyearlylogger
1
 2‐001‐02
 1.3 Dateofmonthlylogger 2‐001‐03 Log 01‐12 
 1.4 Dataofmonthlylogger
1
 2‐001‐04
 1.5 E1High‐resolution
2 CoolingenergyE3  2‐002‐00
 2.1 Dateofyearlylogger 2‐002‐01 Log01‐02
 2.2 Dataofyearlylogger
1
 2‐002‐02
 2.3 Dateofmonthlylogger 2‐002‐03 Log 01‐12 
 2.4 Dataofmonthlylogger
1
 2‐002‐04
 2.5 E3High‐resolution
