Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

58
KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017


4.2 MountingofMULTICAL®603calculator
4.2.1 Compactmounting
Compactmountingmeans thatthecalculatoris
mounteddirectlyonULTRAFLOW®.Ifthereisriskof
condensation(e.g.incoolingapplications),the
calculatoroughttobewall‐mounted.Furthermore,
incoolingapplicationsULTRAFLOW®mustbethe
condensation‐proofversion.
TheconstructionofMULTICAL®603canprovide
minimuminstallation
depth,usingananglefitting
whenmountingULTRAFLOW®.Duetothedesign
themountingradiusremains75mmincritical
places.


4.2.2 Wallmounting
Thecalculatorcanbemounteddirectlyonaneven
wall.Wallmountingrequiresawallfitting(3026‐
207),whichisavailableasanaccessoryto
MULTICAL

603.MULTICAL

603ismountedonthe
wallfittingbyslidingthecalculatorontothefittingin
thesamewayasitisdonebycompactmounting.


4.2.3 Positionofcalculator
Iftheflowsensorisinstalledinhumidorcondensing
environment,thecalculatormustbewallmounted
andpositionedhigher
thantheflowsensor.




Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
