Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017
47

3.2.9 Coldwaterleakage(In ‐A,In‐B)>N<
ThepulseinputsAandBofMULTICAL®603canbeusedforcoldwaterleakagemonitoring.Basically,however,cold
water leakage monitoring is only active on input A (A1/A2), un less otherwise agreed with the customer. When
MULTICAL®603isusedfor
leakmonitoring,thesensit ivityisdeterminedbytheconfigurationoftheN‐code.
Leakagemonitoringismeasuredoveraperiodof24hours.TheNcodedefinestheresolutionbywhichthe24hours
aredivided;either48intervalsofhalfanhour,24intervalsofonehouror12
intervalsoftwohours.Ifthemeter
registersminimumonepulseduringeachoftheseintervalsoverthefullperiod,infocode8,whichindicatesleakage,
isactivated.Theinfocodeisnotactivateduntilafterthe24‐hourperiod,howeveritisresetagainassoonasthemeter
registers
anintervalwithoutpulses.
ThetablebelowshowsthethreeavailableN‐codes.UponreceiptofordertheN‐codeisconfiguredat2bydefault
(unlessotherwiseinformedbythecustomer).
Coldwaterleakagesear ch(In‐A1/A2) N‐code
Noactiveleaksearch 0
30min.withoutpulses 1
Onehourwithoutpulses 2
Twohourswithoutpulses 3

3.2.10 PulseoutputsCandD>PP<
MULTICAL®603canhaveup tofour pulseoutputs (C1,C2, D1andD2) whichareplaced onthe communication
modules(seeparagraph11forfurtherdetailsonmodules).Thepulseoutputshavethreeapplicationoptions:
- Thesendingofselectedmetercount
registers(whicharedeterminedbytheselectedcountrycode).
- Controlledoutput,whichmeansthatthepulseoutputscanbecontrolledbydatacommands.
- Pulsetransmitter/dividersothatthepulsesignalfromV1andV2issentviathepulseoutputs.
PulseoutputsCandDareplacedonselected
communicationmodules.Ifthemoduleisinstalledinmoduleslot1of
MULTICAL®603,theoutputsC1andD1areidentified,andlikewiseformoduleslot2;C2andD2.




Note:
ThepulseoutputsC1andC2arealwaysconfiguredidentically,andlikewise,theoutputsD1
andD2arealwaysconfiguredidentically.Allfouroutputsareconfiguredthroughthemeter’s
PPcode.Therefore,payspecialattentiontothiswhenthemodulesareinstalledinthemeter,
sothattheyareinstalled
inthecorrectmoduleslotinregardtotheequipmenttheyaretobe
connectedto.
D2
C2
D1
C1

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
