10 Powersupply
MULTICAL®603ispoweredviathetwo‐poleconnectorinthecalculatorbase.Theinternalpowersupplyis3.6VDC
andcanbecarriedoutasbatteryormainssupplyviaanumberofdifferentsupplymodulesfromKamstrupA/S,see
thebelowextractfromthetypenumberoverviewinparagraph
3.1.
Supplymodules

Battery,1xD‐cell  2
230VAChigh‐powerSMPS  3
24VAC/VDChigh‐powerSMPS  4
230VACsupplymodule  7
24VACsupplymodule  8
Battery,2xA‐cells  9

Allsupplymoduleshavebeenevaluatedinconnectionwiththeextensivetypetests,towhichMULTICAL®603has
beensubjected,anditisnotpermissibletouseothersupp lymodulesthantheonesmentionedabove.Thesupply
modulesarecoveredbytheCE‐markingandthefactoryguaranteeof
themeter.
Note:Themodulesformainsconnectionmustnotbeconnectedtodirectcurrent(DC),howeverexceptformodule
no.4“24VAC/VDCHighpowerSMPS”.
10.1 Lithiumbattery,2xA‐ce lls
BatterysupplyforMULTICAL®603canconsistofasupplymodulewhichuses2xA‐celllithiumbatteries(Kamstrup
typeHC‐993‐09).Notoolsarerequiredinordertomountorreplacethebatterymodule.Eachbatterycellhasa
lithiumcontentofapprox.0.9g,whichexceptsthe
modulefrombeingsubjecttoregulationsfortransportationof
dangerousgoods.

Thebatterylifetimedependsonfactorslikeambienttemperatureandmeterconfiguration,anindicationofbattery
lifetimeisthusarealisticestimate.

