Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

144
KamstrupA/S∙Technicaldescription∙5512‐2029
_
A1_GB
_
06.2017

11.4 Mountingofantenna
ThewirelessM‐Busmodulesmustbeconnectedtoaninternaloranexternalantenna.
Whenmountinganexternalantenna,youmustmakesurethattheantennacableisarrangedasshownbelow
topreventitfrombeingdamagedwhenthecalculatorisassembled.Beforeexchangingormountingmodules,
thesupplytothemetermustbedisconnected.Thesameappliestothemountingofanantenna.











11.5 Retrofittingmodules
ModulesforMULTICAL

603arealsosuppliedseparatelyforretrofitting.Themodulesarefactory‐configuredand
readyfor installation.However,somemodules requirefinalindividual configuration,whichcan becarried outby
meansofthePCprogramMETERTOOLHCW(readmoreaboutMETERTOOLHCWinthetechnicalDescription5512‐
2096).Beforeexchangingormountingmodules,thesupplytothemetermustbedisconnected.Thesameappliesto
themountingofanantenna.

Type
No.
Module Possibleconfigurationafterinstallation
10 Data+2pulseinputs(In‐A,In‐B)
Pulsefigureandpre‐settingofIn‐AandIn‐Bcanbe
changedviaMETERTOOLHCW.
11 Data+2pulseoutputs(Out‐C,Out‐D)
PulsedurationofOut‐CandOut‐Dischanged via
METERTOOLHCW.
20 M‐Bus+2pulseinputs(In‐A,In‐B)
PulsefigureandpresetofIn‐AandIn‐Bcanbechanged
viaMETERTOOLHCW.
PrimaryandsecondaryM‐Busaddressescanbechanged
viaMETERTOOLorM‐Bus.TheregistercontentsoftheM‐
Busdatapackagecan
bechangedviaMETERTOOLHCW
andREADYManager.
21 M‐Bus+2pulseoutputs(Out‐C,Out‐D)
PulsedurationofOut‐CandOut‐Dischanged via
METERTOOLHCW.
PrimaryandsecondaryM‐Busaddressescanbechanged
viaMETERTOOLorM‐Bus.TheregistercontentsoftheM‐
Busdatapackagecanbechangedvia
METERTOOLHCW
andREADYManager.
WirelessM‐Busmodulewithinternal

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
