MULTICAL®603
KamstrupA/S∙Technicaldescription∙55122029
_
A1_GB
_
06.2017
123
9.3 ShortdirectEN1434temperaturesensor
TheshortdirecttemperaturesensorhasbeendesignedaccordingtotheEuropeanstandardforheatenergymeters
EN14342.Thetemperaturesensorisconstructedtobemounteddirectlyinthemeasuringmedium,i.e.without
sensorpocket,bywhichyouobtainanextremelyfastresponsetotemperaturechangesfrome.g.domestic
water
exchangers.
Thesensorisbasedontwowiresiliconecable.Thesensorpipeismadeofstainlesssteelandhasadiameterof4
mmatthepoint,wherethesensorelementisplaced.Furthermore,itcanbedirectlymountedinmanyof
Kamstrup’sflowsensortypes,whichreduces
theinstallationcosts.Theshortdirectsensorisavailableina27.5mm
version,typeDS27.5mm,andina38mmversion,typeDS38mm.TheshortdirectsensorcanbeusedinPN16
installationswithamaximummediumtemperatureof150°C.

Figure6
Figure7

As it appears from Figure 6, the short
directsensorDS27.5mmcanbemounted
bymeansofanorforM10nipple
inastandard90tee.
In order to obtain the best possible
serviceabilityduringmeterreplacement,the
shortdirectsensorcanbe placedin aball
valvewithsensorsocket,seeFigure7.
Ballvalveswithsensorsocketsareavailable
inG½,G¾,G1,allofwhichfittheDS27.5
mmsensoraswellas
inG1¼andG1½, both
fittingtheDS38mmsensor.
No. 6556474 6556475 6556476
G1
No. 6556526 6556527
G1¼ G1½
