Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017
145

22 M‐Bus+ThermalDisconnect
PrimaryandsecondaryM‐Busaddressescanbechanged
viaMETERTOOLorM‐Bus.TheregistercontentsoftheM‐
BusdatapackagecanbechangedviaMETERTOOLHCW
andREADYManager.
30
WirelessM‐Bus+2pulseinputs
(In‐A,In‐B)
Pulsefigureandpre‐settingofIn‐AandIn‐Bcanbe
changedviaMETERTOOLHCW.Theregistercontentsof
theM‐BusdatapackagecanbechangedviaMETERTOOL
HCWandREADYManager.
31
WirelessM‐Bus+2pulseoutputs
(Out‐C,Out‐D)
Pulsefigureandpre‐settingofOut‐CandOut‐Dcanbe
changedviaMETERTOOLHCW.Theregistercontentsof
theM‐BusdatapackagecanbechangedviaMETERTOOL
HCWandREADYManager.
40 Analogoutputmodule,with2x0/4…20mA
Outputas0…20mAor4…20mA.Outputfromoneofthe
followingregisters:FlowV1,power,inlettemperaturet1,
outlettemperaturet2,differentialtemperaturet1‐t2.
TheabovevaluescanbechangedviaMETERTOOLHCW
andareindividualforeachof
thetwooutputs.
41
Analoginputmodule,with2x0…20mAor
0...10V
Inputas0…20mAor0…10V.Inputarereadby
MULTICAL®forlogginganddisplayreading.Thetwo
inputscanbeconfiguredwithmeasuringranges,
measuringunitsanddecimalpoints.
ThesecanbechangedwithMETERTOOLHCW.
60
LONFT‐X3+2pulseinputs(In‐A,In‐B)
Pulsefigureandpre‐settingofIn‐AandIn‐Bcanbe
changedviaMETERTOOLHCW.
66 BACnetMS/TP+2pulseinputs(In‐A,In‐B)
Pulsefigureandpre‐settingofIn‐AandIn‐Bcanbe
changedviaMETERTOOLHCW.
TheMACaddresscanbechangedwithMETERTOOLHCW.
67 ModbusRTU+2pulseinputs(In‐A,In‐B)
Pulsefigureandpre‐settingofIn‐AandIn‐Bcanbe
changedviaMETERTOOLHCW.
TheRTUslaveaddresscanbechangedwithMETERTOOL
HCW.

 

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
