MULTICAL®603
KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017
19
Type603‐ □□
‐
□
‐
□□
‐
□□
Pocketsensorpair ø5.8mm 3.0m 32
Pocketsensorpair ø5.8mm 5.0m 33
Pocketsensorpair ø5.8mm 10.0m 34
Pocketsensorpair(3pairs) ø5.8mm 1.5m 35
Pocketsensorpair(3pairs) ø5.8mm 3.0m 36
Pocketsensorpair(3pairs) ø5.8mm 5.0m 37
Pocketsensorpair(3pairs) ø5.8mm 10.0m 38
Pt100temperature senso rpair
Shortdirectsensorpair 27.5mm 2.0m J1
Shortdirectsensorpair 38.0mm 2.0m J2
Supply
Nosupply 0
Battery,1xD‐cell 2
230VAChigh‐powerSMPS 3
24VAC/VDChigh‐powerSMPS 4
230VACpowersupply 7
24VACpowersupply 8
Battery,2xA‐cells 9
Communicationmodule(2moduleslots)
Nomodule 00 00
Data+2pulseinputs(In‐A,In‐B) 10 10
Data+2pulseoutputs(Out‐C,Out‐D)+pulsetransmitter(V1+V2) 11 11
M‐Bus,configurable+2pulseinputs(In‐A,In‐B) 20 20
M‐Bus,configurable+2pulseo utputs(Out‐C,Out‐D)
21 21
M‐Bus,configurablew/ThermalDisconnect 22 22
WirelessM‐Bus,EU,configurable,868MHz+2pulseinputs(In‐A,In‐B) 30 30
WirelessM‐Bus,EU,configurable,868MHz+2pulseoutputs(Out‐C,Out‐D) 31
31
Analogoutputmodule2x0/4…20mA 40 40
Analoginputmodule2x0/4…20mA 41
41
KamstrupRadio+2pulseinputs(In‐A,In‐B) 50 50
LONFT‐X3+2pulseinputs(In‐A,In‐B) 60
60
BACnetMS/TP(RS‐485)+2pulseinputs(In‐A,In‐B) 66 66
ModbusRTU(RS‐485)+2pulseinputs(In‐A,In‐B) 67 67
HighPowerRadioRouter+2pulseinputs(In‐A,In‐B) 84 84
