Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017
31

   
Displayref.
Primaryreading

Displayref.
Secondaryreading
 
Heatmeter
DDD=110
Heatmeter
DDD=210
Heat/coolingmeter
DDD=310
Heatmeter
DDD=410
Coolingmeter
DDD=510
Heat/coolingmeter
DDD=610
Volumemeter
DDD=710
21.0 TA4   13 13 14 13 13 14 8
  21.1 TL4 13A 13A 14A 13A 13A 14A 8A
22.0
A1Heatenergywith
discount(A‐)
        
  22.1
A2

Heat

energy

with

surcharge

(A+)
      
  22.2 t5       
23.0 CP(movingaverage)  
  23.1 CurrentpowerofinputB1
5
       
  23.2 Dateofyearlylogger
      
  23.4 Dataofyearlylogger
1

  23.5 Dateofmonthlylogger
      
  23.6 Dataofmonthlylogger
1

24.0 Infocode 14 14 15 14 14 15 9
  24.1 Infoeventcounter 14A 14A 15A 14A 14A 15A 9A
  24.2 Dateforinfologger
14B 14B 15B 14B 14B 15B 9B
  24.3 Dataforinfologger
25.0
Customerno.
(N
o
1)
  15 15 16 15 15 16 10
  25.1 Customernumber(N
o
2) 15B 15B 16A 15B 15B 16A 10A
26.0
Differentialenergy
(dE)
 
  26.1 Controlenergy(cE) 
27.0
Differentialvolume
(vold)
 
  27.1 Controlvolume(volc) 

1
Dependingontheselecteddepthofyearlyandmonthlylogsintheprogrammabledatalogger,thesedisplayreadings
canbeempty.
2
Theaverageisvolumebased
3
Onlythedateofmin./maxisdisplayedinformat20xx.xx.xx.Serialreadingincludesthetime(hh.mm)oftheaverage
valuecalculationtoo.
4
InputsAandBareregularlyupdatedinthedisplayofMULTICAL®603,i.e.thedisplayoftheconnectedwateror
electricitymeterwillbeinaccordancewiththedisplayofMULTICAL®603withoutdelay.
5
TheunitofthisreadingisfixedatkW. 

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
