Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017
55

Offsetoft1andt2(±0.99K)
4

(Seeparagraph7.3)
Tobeenteredonthe
basisofR
0
ofthe
sensorelementaswell
asthecableresistance.
Ifnosensordatais
available,offsetisset
to0.00K.
‐ ‐
t2preset
Onlyactiveifmetertype4is
selected.
‐
0,01…185.00C+250.00C 250.00C
t3preset

‐
0,01…185.00C+250.00C 250.00C
t4preset

‐
0,01…185.00C+250.00C 5.00C
t5preset
Onlyrelevantformetertypes1
and2.(Seeparagraph7.1.3)
‐
0.01…185.00C 50.00C
Schedulerprofile
(Seeparagraph7.12)
‐ Createdschedulerprofiles
Dependsonthecountry
code
(Defaultdeactivated)
DST
(DaylightSavingTime)
(Seeparagraph7.11)
‐ Enabled/Disabled
Dependsoncountry
code

1
Serial no. (factory set unique serial number) is written on the meter and cannot be changed after factory
programming.
2
Yearlytargetdate2(MM.DD)andmonthlytargetdate2(DD)aresetto00.00and00,respectively.Ifthesetarget
datesaredisabled,themeterjustusesyearlytargetdate1andmonthlytargetdate1.
3

hc
=250.00  Cdisconnectsthefunction.Inallothermetertypesthan6, 
hc
isdisabledandcannotbeenabledafter
delivery.
4
ApplyingbothtotheinternalM‐Busandthetwomoduleslotsinthemeter.Atsubmissionoforder,youcanchoose
“fixedM‐Busaddress”whichmeansthatallmetersincludedintheorderareconfiguredwiththesameprimaryaddress.
5
R
0
istheresistancevalueofthesensorelementinohm(Ω)at0°C.




Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
