Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

72
KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017

 
Primaryreading

Secondaryreading

Index
numberin
display

Logging
depth/refere
ncenumber

201 InfoModule2Configno.
6
  2‐201‐00 N
o
31
 201.1 Firmwarerevision
6
2‐201‐01 N
o
32
 201.2 Moduleserialnumber
6
2‐201‐02 N
o
33
 201.3 Primaryaddress
6
2‐201‐03 N
o
34
 201.x M‐Bussecondaryaddressing
7
2‐201‐xx N
o
35
 201.x M‐Busenhancedsecondary
addressing
7

2‐201‐xx N
o
36
 201.x KM‐RFfrequency
7
2‐201‐xx N
o
37
 201.x KM‐RFnetworkaddress
7
2‐201‐xx N
o
38

1
Dependingontheselecteddepthofyearlyandmonthlylogsintheprogrammabledatalogger,thesedisplay
readingscanbeempty.
2
Thetemperatureaverageisvolume‐based.
3
Onlythedateofmin./maxisdisplayedintheformat20xx.xx.xx.Byserialreading,thetime(hh.mm)isincludedtoo.
4
InputsA1,B1,A2andB2areupdatedcontinuouslyinthedisplayofMULTICAL®603,i.e.thedisplayoftheconnected
waterorelectricitymeterwillbeinaccordancewiththedisplayofMULTICAL®603withoutdelay.
5
TheunitofthisreadingisfixedatkW.Thereadingupdatesatthesamespeedastheintegrationinterval,whichis
determinedbytheL‐code.
6
Thesearefixedreadingsundermoduleinfo.
7
Thesereadingsdependonthemoduleandarethusnotfixedreadings.Dependingonthemodule,theorderofthe
readingscanvary.Therefore,theindexnumberissetto“xx”.
 

Kamstrup MULTICAL 603 Specifications

General

Flow Sensor	Ultrasonic
Battery Life	Up to 16 years
Power Supply	Battery
Communication Options	M-Bus, Wireless M-Bus, Modbus, BACnet
Display	LCD
Application	Heating and Cooling
Pressure Rating	PN16
Approval	MID
Accuracy	Class 2
Ambient Temperature Range	55°C
Housing Material	Brass
