Kamstrup MULTICAL 603 Technical Description

MULTICAL®603

90
KamstrupA/S∙Technicaldescription∙5512‐2029_A1_GB_06.2017



603‐E/F
Applicationno.9

2coolingcircuitswithjointforw ar dpipe

Coolingenergy#1:E4=V1(t1‐t3)k
t1:Inlet

Coolingenergy#2:E5=V2(t2‐t3)k
t2:Inlet









ConfigA=3(inlet)or4(outlet)
(noinfluenceonE2,E4orE5)


603‐A/B/C/D/E/F/G
Applicationno.10
Energyofdom e stic hotwaterE1=V1(t1‐t2)K
t1:Flow

t1ismeasuredwitha2‐wiresensor(603‐A/C/E/F)ora
4‐wiresensor(603‐B/D/G)
t2ismeasuredeitherwitha2‐wiresensor(603‐A/C/E/F)
ora4‐wiresensor(602‐B/D/G)
or
t2isprogrammedwithafixedtemperaturevalue
or
t2isprogrammedviathe
schedulerfunctionthatis
integratedinMULTICAL® 603.Temperaturet2followsa
tablewithinwhicht2canbechangedupto12timesa
year.
Config.A=3(Inlet)


0
5
10
15
20
25
jan feb mar apr may jun jul aug sep oct nov dec
Return temperature
Date
Scheduler function
