Series 2600B

System SourceMeter® Instrument Reference Manual Section 7:

TSP command reference

2600BS-901-01 Rev. C / August 2016 7-251

Details

The SMU will automatically clear all the event detectors when the smuX.trigger.initiate()

function is executed. This function should be called after the sweep is initiated.

A common example of when this function can be used is when you want the SMU to immediately

perform an action the first time through the trigger model even if a programmed trigger event does not

occur.

This function can also be used to start actions on the SMU in case of a missed trigger event.

Example

smua.trigger.arm.set()

Sets the arm event detector to the

detected state for SMU channel A.

Also see

smuX.trigger.initiate() (on page 7-259)

smuX.trigger.measure.set() (on page 7-261)

smuX.trigger.source.set() (on page 7-271)

smuX.trigger.arm.stimulus

This attribute selects the event that will cause the arm event detector to enter the detected state.

Type TSP-Link accessible Affected by Where saved Default value

Attribute (RW)

Yes

SMU reset

Instrument reset

Recall setup

Not saved

Usage

eventID = smuX.trigger.arm.stimulus

smuX.trigger.arm.stimulus = eventID

eventID

Event that triggers the arm detector

Source-measure unit (SMU) channel (for example,

smua.trigger.arm.stimulus

applies to SMU channel A)
