Example
smua.source.limitv = 30
Sets the voltage limit of SMU
channel A to 30 V.
Also see
DUT test connections (on page 2-49)
smuX.source.compliance (on page 7-236)
smuX.source.func (on page 7-237)
smuX.source.output (on page 7-244)
smuX.source.lowrangeY
This attribute sets the lowest source range that will be used during autoranging.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Saved setup
Voltage:
Models 2601B/2602B/2604B: 100e-3 (100 mV)
Models 2611B/2612B/2614B/2634B/2635B/2636B:
200e-3 (200 mV)
Current:
Models 2601B/2602B/2604B/2611B/2612B/2614B:
100e-9 (100 nA)
Models 2634B/2635B/2636B: 1e-9 (1 nA)
Usage
sourceRangeLow = smuX.source.lowrangeY
smuX.source.lowrangeY = sourceRangeLow
sourceRangeLow
Set to the lowest voltage (in volts) or current (in amperes) range to be used
X
Source-measure unit (SMU) channel (for example, smua.source.lowrangev
applies to SMU channel A)
Y
SMU source function (v = voltage, i = current)
Details
This attribute is used with source autoranging to put a lower bound on the range that is used. Lower
ranges generally require greater settling times. If you set a low-range value, you might be able to
source small values with less settling time.
If the instrument is set to autorange and it is on a range lower than the one specified by
sourceRangeLow, the source range will be changed to the range specified by sourceRangeLow.
Example
smua.source.lowrangev = 1
Sets volts low range for Models
2601B/2602B/2604B SMU A to 1
V. This prevents the source from
using the 100 mV range when
sourcing voltage.
Also see
smuX.source.autorangeY (on page 7-234)
