Keithley 2600B User Manual

Section
7: TSP command reference Series 2600B System SourceMeter® Instrument
Reference Manual
7-224 2600BS-901-01 Rev. C / August 2016
Example
smua.measure.lowrangev = 1
Sets voltage low range for SMU channel A to 1 V.
Also see
Range (on page 2-81)
reset() (on page 7-173)
setup.recall() (on page 7-194)
smuX.measure.autorangeY (on page 7-214)
smuX.reset() (on page 7-232)
smuX.measure.nplc
This command sets the integration aperture for measurements.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Instrument reset
SMU reset
Recall setup
Saved setup
1.0
Usage
nplc = smuX.measure.nplc
smuX.measure.nplc = nplc
nplc
The integration aperture; set from 0.001 to 25
X
Source-measure unit (SMU) channel (for example, smua.measure.nplc applies
to SMU channel A)
Details
This attribute controls the integration aperture for the analog-to-digital converter (ADC).
The integration aperture is based on the number of power line cycles (NPLC), where 1 PLC for 60 Hz
is 16.67 ms (1/60) and 1 PLC for 50 Hz is 20 ms (1/50).
Example
smua.measure.nplc = 0.5
Sets the integration time for SMU channel A to 0.5/60
seconds.
Also see
reset() (on page 7-173)
setup.recall() (on page 7-194)
smuX.reset() (on page 7-232)
Speed (on page 2-87)
