Keithley 2600B User Manual

Appendix
C: LAN concepts and settings Series 2600B System SourceMeter® Instrument
Reference Manual
C-14 2600BS-901-01 Rev. C / August 2016
Searching for DNS server(s)
Starting DLLA Configuration
DLLA Failed
DLLA configuration started on xxx.xxx.xxx.xxx
Starting Manual Configuration
Manual configuration started on xxx.xxx.xxx.xxx
Closed
Viewing the network settings
To view the active network settings:
1. From the front panel, press the MENU key, and then select LAN > STATUS.
2. Use the navigation wheel
to select one of the following network settings:
• IP-ADDRESS
• GATEWAY
• SUBNET-MASK
• METHOD
• DNS
• MAC-ADDRESS
1. Press the ENTER key to view the active setting.
2. Press the EXIT (LOCAL) key once to return to the STATUS menu.
Confirming the active speed and duplex negotiation
The Series 2600B automatically detects the speed and duplex negotiation active on the LAN. Once
the speed and duplex negotiation is detected, the instrument automatically adjusts its own settings to
match the LAN settings.
To confirm the active LAN speed and duplex mode:
1. From the front panel, press the MENU key.
2. Select LAN > STATUS.
3. Use the navigation wheel
to select one of the following:
• SPEED
• DUPLEX
1. Press the ENTER key to view the active setting.
2. Press the EXIT (LOCAL) key once to return to the STATUS menu
