Keithley 2600B User Manual

Series 2600
B System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. C / August 2016 7-335
As an example, to set bit B1 of the questionable status instrument summary enable register, set
status.questionable.instrument.enable =
status.questionable.instrument.SMUA.
In addition to the above constants, questionableRegister can be set to the numeric equivalent of
the bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B1 and B2, set questionableRegister to 6 (which is
the sum of 2 + 4).
Example
status.questionable.instrument.enable =
status.questionable.instrument.SMUA
Uses a constant to set the SMUA bit
of the questionable status
instrument summary enable register.
Also see
Questionable Status Registers (on page E-13)
status.questionable.* (on page 7-330)
status.questionable.instrument.smuX.*
This attribute contains the questionable status SMU X summary register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute
- -
- -
- -
- -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW)
Yes
Status reset
Not saved
0
.event (R)
Yes
Status reset
Not saved
0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW)
Yes
Status reset
Not saved
4864 (All bits set)
Usage
questionableRegister = status.questionable.instrument.smuX.condition
questionableRegister = status.questionable.instrument.smuX.enable
questionableRegister = status.questionable.instrument.smuX.event
questionableRegister = status.questionable.instrument.smuX.ntr
questionableRegister = status.questionable.instrument.smuX.ptr
status.questionable.instrument.smuX.enable = questionableRegister
status.questionable.instrument.smuX.ntr = questionableRegister
status.questionable.instrument.smuX.ptr = questionableRegister
questionableRegister
The status of the questionable status SMU X summary register; a zero (0)
indicates no bits set (also send 0 to clear all bits); other values indicate various
bit settings
X
Source-measure unit (SMU) channel (for example
status.questionable.instrument.smua.enable applies to SMU
channel A)
