Keithley 2600B User Manual

Section
7: TSP command reference Series 2600B System SourceMeter® Instrument
Reference Manual
7-174 2600BS-901-01 Rev. C / August 2016
Details
The reset() command in its simplest form resets the entire TSP-enabled system, including the
controlling node and all subordinate nodes.
If you want to reset a specific instrument, use either the localnode.reset() or
node[X].reset() command. Use the localnode.reset() command for the local instrument.
Use the node[X].reset() command to reset an instrument on a subordinate node.
When no value is specified for system, the default value is true.
You can only reset the entire system using reset(true) if the node is the master. If the node is not
the master node, executing this command generates an error.
Example
reset(true)
If the node is the master node, the entire system is
reset; if the node is not the master node, an error is
generated.
Also see
localnode.reset() (on page 7-156)
savebuffer()
This KISavebuffer factory script function saves a specified reading buffer as either a .CSV file or an .XML file.
Type TSP-Link accessible
Affected by Where saved Default value
Function
No
Usage
savebuffer(buffer, formatType, fileName)
buffer
The reading buffer to save
formatType
A string indicating which file type to use: .csv or .xml
fileName
The file name of the saved buffer
Details
Use this function to save the specified buffer to a USB flash drive.
This function will only save to a USB flash drive.
You are not required to qualify the path to the USB flash drive, but if you wish to, add /usb1/ before
the fileName (see Example 2).
Example 1
savebuffer(smua.nvbuffer1, "csv",
"mybuffer.csv")
Save
smua
dedicated reading buffer 1 as a
.CSV file named mybuffer.csv.
Example 2
savebuffer(smua.nvbuffer1, "csv",
"/usb1/mybuffer.csv")
Save smua dedicated reading buffer 1 to an
installed USB flash drive as a .CSV file
named mybuffer.csv.
