Keithley 2600B User Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. C / August 2016 7-187
scriptVar.source
This attribute contains the source code of a script.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
(see
Details)
No Not applicable Not saved Not applicable
Usage
code = scriptVar.source
scriptVar.source = nil
scriptVar
The name of the variable that references the script that contains the source code
code
The body of the script
Details
The loadscript or loadandrunscript and endscript keywords are not included in the source
code.
The body of the script is a single string with lines separated by the new line character.
The instrument automatically stores the source for all scripts that are loaded on the instrument. To
free up memory or to obfuscate the code, assign nil to the source attribute of the script. Although
this attribute is writable, it can only be set to the nil value.
Example
test7 = script.new("display.clear() display.settext('Hello from my test')", "")
print(test7.source)
This example creates a script called "test7" that displays a message on the front panel and retrieves the
source code.
Output:
display.clear() display.settext('Hello from my test')
Also see
scriptVar.list() (on page 7-183)
serial.baud
This attribute configures the baud rate for the RS-232 port.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Not applicable
Nonvolatile memory
9600
Usage
baud = serial.baud
serial.baud = baud
baud
The baud rate (300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600 or
115200)
