Keithley 2600B User Manual

Section
7: TSP command reference Series 2600B System SourceMeter® Instrument
Reference Manual
7-128 2600BS-901-01 Rev. C / August 2016
Details
This attribute specifies the default gateway IP address to use when manual or DLLA configuration
methods are used to configure the LAN. If DHCP is enabled, this setting is ignored.
This attribute does not indicate the actual setting that is presently in effect. Use the
lan.status.gateway attribute to determine the present operating state of the LAN.
The IP address must be formatted in four groups of numbers, each separated by a decimal.
Example
print(lan.config.gateway)
Outputs the default gateway address. For example,
you might see the output:
192.168.0.1
Also see
lan.restoredefaults() (on page 7-132)
lan.status.gateway (on page 7-135)
lan.config.ipaddress
This attribute specifies the LAN IP address.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
LAN restore defaults
Nonvolatile memory
"192.168.0.2"
Usage
ipAddress = lan.config.ipaddress
lan.config.ipaddress = ipAddress
ipAddress
LAN IP address; must be a string specifying the IP address in dotted decimal
notation
Details
This attribute specifies the LAN IP address to use when the LAN is configured using the manual
configuration method. This setting is ignored when DLLA or DHCP is used.
This attribute does not indicate the actual setting that is presently in effect. Use the
lan.status.ipaddress attribute to determine the present operating state of the LAN.
Example
ipaddress = lan.config.ipaddress
Retrieves the presently set LAN IP address.
Also see
lan.restoredefaults() (on page 7-132)
lan.status.ipaddress (on page 7-136)
