Keithley 2600B User Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. C / August 2016 7-299
Usage
operationRegister = status.operation.instrument.digio.condition
operationRegister = status.operation.instrument.digio.enable
operationRegister = status.operation.instrument.digio.event
operationRegister = status.operation.instrument.digio.ntr
operationRegister = status.operation.instrument.digio.ptr
status.operation.instrument.digio.enable = operationRegister
status.operation.instrument.digio.ntr = operationRegister
status.operation.instrument.digio.ptr = operationRegister
operationRegister
The status of the operation status digital I/O summary register; a zero (0) indicates
no bits set (also send 0 to clear all bits); the only valid value other than 0 is 1024
Details
These attributes are used to read or write to the operation status digital I/O summary registers.
Reading a status register returns a value. The binary equivalent of the returned value indicates which
register bits are set. The least significant bit of the binary number is bit B0, and the most significant bit
is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
Status register set
contents (on page E-1) and Enable and transition registers (on page E-19). The individual bits of this
register are defined in the following table.
Bit Value Description
B0-B9
Not used
Not applicable
B10
status.operation.instrument.digio.TRIGGER_OVERRUN
status.operation.instrument.digio.TRGOVR
Set bit indicates an
enabled bit in the
Operation Status Digital
I/O Overrun Register is set.
Bit B10 decimal value:
1,024
Binary value:
0100 0000 0010
B11-B15 Not used Not applicable
In addition to the above constant, operationRegister can be set to the decimal equivalent of the
bit to set.
Example
status.operation.instrument.digio.enable =
status.operation.instrument.digio.TRGOVR
Sets the TRGOVR bit of the
operation status digital I/O summary
enable register using a constant.
Also see
Operation Status Registers (on page E-9)
status.operation.instrument.digio.trigger_overrun.* (on page 7-300)
