Keysight N9927-90001 User’s Guide 211
SA (Spectrum Analyzer) Mode
How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA
Mode (Option 233–Mixed Analyzers))
— Default Receiver side only antenna measurements.
— Src/Rcvr Split
to work with non-triaxial receiver
and source side antenna measurements.
— Triaxial XYZ
(default, when Channel Power is on and
when a compatible triaxial antenna’s factors have
been imported) for measuring channel
measurements and EMF.
— Then Back
to exit to the previous softkey menu.
e. Optional:
Verifying antenna and cable corrections are applied:
i. Press Scale/Amptd
> Corrections > Apply Corrections OFF
ON
Verify the Apply Corrections softkey is set to ON (This is the
default setting when a compatible USB antenna’s correction
factors have been imported, via the System softkeys).
Verify the X axis Antenna
, Y axis Antenna, and Z axis Antenna
are all ON. These can each be enabled or disabled
individually, but for EMF measurements all three axes should
be enabled (i.e., Antenna = Off, the applications are setting
the X/Y/Z).
Verify Cable
is ON. This can be disabled for applications
where an additional cable has not been connected to the
triaxial antenna. Before a cable can be used with the EMF
measurements it needs to have corrections loaded. If you are
going to use a cable, then choose as needed:
— Cable Off
to open the cable correction softkeys menu
— Edit Cable
displays a cable corrections table
that you can edit
— New
displays a cable corrections table that
you can edit with new cable correction
content.
——Choose Yes
to overwrite the current
cable data
——Choose No
to exit the cable data
edit table view
— Save Cable
Opens a menu to name and save
the cable corrections data
— Recall Cable
Recalls the selected cable
correction file from the \Cables folder.
