Keysight N9927-90001 User’s Guide 299
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2
Only)
How to Set Up Over–the–Air (OTA) Mode Settings
——Optional: Then Meas Interval > ON
——Then Interval Type
> choose Time or
Distance.
——Then, if applicable Time Interval
enter
time interval in seconds.
Or
——Then, if applicable Distance Interval
enter distance interval in miters.
——Then Back
14. If recording, then:
— Pause Resume
Temporarily halts recording until pressed again. The
incoming trace continues to sweep. Press again to continue
recording.
— Stop
Immediately stops recording. Then choose from the following:
— Press Save Log File
to save the current Table data (i.e.,
default save device is Internal). i.e., *.KML (default) or
*.CSV files are saved to the filename and device type. See
Settings below and “To change Recording Configuration
settings:” on page 323.
— Press Record
to continue recording.
— Then Settings
To change your file settings or and
measurement interval. Learn more, refer to “To change
Recording Configuration settings:” on page 323.
— Save Log File
15. Export KML file into 3rd party mapping software (i.e., Google Map or
Google Earth). Refer to “Step 6: Import and Play back KML Files into 3rd
Party Software (Example: Google Earth with Animation Tool)” on page 313.
Record-Play files are saved to:
— Record-Play files are save-recalled to:
"[CurrentDevice]\RecordPlayback\OTA"
