Keysight N9927-90001 User’s Guide 345
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
5. Entering the phased array antenna measurement type:
Refer to “Data Formats:” on page 332.
Select Measure
:
— Measure
—choose:
— Bore-Sight
or
— Heat Map
or
— Polar ANT
or
— Park ANT
6. Using the table to enter phased array antenna settings, presetting the
antenna, setting the antenna LAN IP, and clearing the graphics:
Refer to Figure 15 on page 351.
Select Meas Setup
:
— Antenna Settings
—choose:
—Ball Antenna > LAN Address
—Settings–choose:
——Res BW or
——Video BW
——Beam Width
— Array Antenna–choose:
——Center
——Azimuth Ref
——Elevation Ref
—Polar Display >Ref
—Sweep > Dwell Time (Optional. For pulsed RF
measurements it is recommended that the Dwell Time is
increased.)
—Sweep > Max Hold (Optional. For pulsed RF
measurements it is recommended that Max Hold is set to
OFF when using the Heat Map display. (Default = OFF).)
— Preset Antenna
presets the antenna settings factory defaults.
— Ant LAN IP
enter the Ball antenna’s LAN IP. First three fields must
match the FieldFox’s static IP address (default: 192.168.1.10). Refer
to Figure 14 on page 350.
To Next Page
