Keysight N9927-90001 User’s Guide 437
Interference Analyzer (SA Mode) – Option 236
Record/Playback (SA Option)
—Then Record At the end of each 10 second record interval, the Max Hold
trace is recorded and the Max Hold processing is reset for the next 10
second record interval.
—Then Stop
to end the recording.
This session can be played back into any Trace State. For example:
Play the Max Hold recording into a Clear/Write trace to see the data exactly as
it was recorded.
—Press Trace 6
then with Trace = 1 and press State then Clr/Wr
—Then Record Playback
—Then Play
Play the Max Hold recording into a Max Hold trace to show the accumulation
of “Max Hold” activity over the entire recording.
—Press Trace 6
then with Trace = 1 and press State then Max Hold
—Then Record Player
—Then Play
