Channel Scanner (Option 312)
How to Set Up Channel Scanner
— View Corrections > View Corrections ON OFF Turn ON and OFF
Yellow Trace - Antenna/Cable corrections. This is a composite of all
cable/antenna corrections that are currently applied. Available as a
useful visual aid, the zero “dB” level (no net correction) is mapped to
appear at the -50 dBm on-screen level.
The following menu appears when any of the above Antenna or Cable softkeys
are pressed:
— Antenna/Cable ON OFF
Turn correction ON or OFF for this Antenna/Cable.
— Edit Antenna/Cable
Edit an Antenna/Cable Correction table. See Using the
Antenna/Cable Editor (below) for more information.
— New
Create a new Antenna/Cable. See Using the Antenna/Cable Editor
(below) for more information.
— Save Antenna/Cable
Save the modified Antenna/Cable to a file on the
specified Storage Device.
— Recall Antenna/Cable
Read an existing Antenna/Cable file from the
specified Storage Device.
— Storage Device
Choose from: Internal, USB, SD. Learn more about these
selections in “Set File Type and Select Device” on page 677.
When finished, press Back
to return to the previous menu.
Field Strength Correction Examples
Refer to Figure 26-17 on page 542 and Figure 26-18 on page 543.
